PRODUCT DESCRIPTION
Product details
The Audi/VW 1.4L TSI and TFSI connecting rods are H-beam shaped and made from 4340 high-tensile steel. The bushings are made from AMPCO 18 material, which offers excellent wear and fatigue resistance, and feature a radial groove that acts as an oil reservoir. Additionally, they incorporate a grooved pin end that minimizes deformation under high inertial loads, thereby reducing weight. They undergo shot peening to relieve material stress and multi-stage heat treatment to increase their rigidity. Strict manufacturing process tolerances ensure a perfect fit and optimize oil clearances. Bending and twisting are strictly controlled. They are designed for high performance and extreme durability. Each connecting rod includes ARP 2000 head bolts with a strength of 220,000 psi; optionally, ARP 625 material can be chosen. The complete kit is supplied with ARP molybdenum oil and comprehensive assembly instructions. Additional machining processes
Centering bushings for a perfect fit and precise reassembly
Flanged cap relief for increased connecting rod head integrity in extreme applications
Grooves on the thrust face to reduce weight
ZRP connecting rod technical features
Forged in two pieces for high strength
Shot peened for extended life
Magnaflux inspection ensures that the consistency of the forged material meets our high quality standards
Double ribbed caps for added support
Multi-stage heat treatment for maximum strength, dimensional stability and service life.
CNC machined for superior tolerances, with accuracy up to 0.0002″
Center-to-center tolerance less than 0.001″
Finite Element Analysis (FEA): computer-generated stress analysis for connecting rods
Optimal balancing for sets with matched weight of ± 1 gram
Additional Information
Application
1.4L TFSI (2012-Pre)
Engine Number
CAVD, CAXA, CAVA, BLG, CAX, CAV, CVA
Notes
Connecting rods without spline drilling
Bolt size
5/16"
Shape
H-Beam
Length (CC)
144.00
Pin size
19.00
Big end bore diameter
50.60
Big end width
23.00
Weight (gr.)
467
Set of
4
Fastener Grade
ARP2000
Series
Standard Series
Weight
467
