Turbosmart TS-1-7880VB096E TS-1 High Performance Turbo 7880 V-Band 0.96AR with External Wastegate

Smaller, Lighter, Faster – The Turbosmart TS-1 series of turbochargers has been developed to take advantage of modern materials, design, and manufacturing techniques, creating a range of turbochargers that caters to the demands of both motorsport enthusiasts and high-performance aficionados alike.

TS-1 Series turbochargers are oil-cooled and feature lightweight investment cast stainless steel turbine housings. A patented bearing and main shaft system provides unimaginable transient response, with the performance, quality, reliability, and support that Turbosmart is renowned for.

Ultra-low rotating mass from our unique bearing and shaft assembly combines with aggressive compressor aerodynamics to ensure high performance at low shaft speeds. Plus, it incorporates a unique T14 Inconel turbine wheel to ensure power is maintained at high loads and flow rates.

The TS-1 Series of turbochargers takes a comprehensive approach to increasing engine performance, seeking to achieve power through lower back pressure and high-performance turbochargers, all in a smaller, lighter, and faster format.

Available in:
TS-1 Oil Cooled Turbos
TS-2 Oil & Water Cooled Turbos
V-Band, T3, & T4 Flange Options
Reverse Rotation (Selected Sizes)
Various AR Options
Internal & External Wastegate Options Available

Features:
Unmatched Transient Response
Aggressive Aerodynamics with 7+7 Splitter Wheels
Lightweight 310s Investment Cast Stainless Steel Turbine Housings
Lightweight Billet Aluminum Compressor Covers
CFD Designed Housings for Optimal AR & Flow
T14 Inconel Turbine Wheel for Extreme EGT’s
VSR Speed Balanced
Patented Dual Ceramic Ball Bearing System
Integrated Iron Backplate Into Center

Specifications

Power: 1425 HP

Compressor Inlet: 4” / 101.6mm
Compressor Inducer: 78mm
Turbine Inlet: V-Band (3.00”)
Turbine Exducer: 80mm
Turbine A/R: 0.96
Turbine Outlet: V-Band (3.50”)
Weight: 6.43 kg / 14.17 lbs
