Wilwood 140-17568-R NDPR Front Brake Kit for UTV, Red, Compatible with Polaris RZR.

NDPR Front UTV Brake Kit (Red)

Wilwood’s NDPR Front and Rear UTV Brake Kits feature dynamic mount rotors and enhanced calipers for popular off-road vehicles. They combine fixed-mount multi-piston calipers with increased clamping force and larger diameter floating rotors for greater brake torque, improving braking performance on high-horsepower UTVs. Four-piston forged aluminum calipers reduce deflection and provide more even engagement for increased stopping power and improved feel. The high-friction steel rotors are up to 20% larger in diameter and thicker for less warping. Dynamic mount rotors reduce thermal stress and prevent piston knockback on rough terrain. Kit Summary

Spindle Type:

Disc

Mount Type:

Radial

Caliper Type:

4 - Red Powder Coat

Rotor Diameter:

11.25

Minimum Required Wheel Diameter*:

14

Calipers

Left - Part #:

120-17565-RD

Right - Part #:

120-17565-RD

Type:

NDPR

Finish Color:

Red Powder Coat

Number of Pistons:

4

Piston Diameter 1 (in):

1.75

Piston Diameter 2 (in):

1.75

Piston Diameter 3 (in):

0
Piston Area (in²):

4.80

Piston Type:

Stainless

Mount Type:

Radial

Brake Pad Plate:

7812

Brake Pad Area (in²):

6.36

Brake Pad Volume (In³):

2.1

Pad Compound:

BP-10

Rotors

Left - Part #:

160-16515

Right - Part #:

160-16515

Type:
Solid Steel Rotor

Style:
Smooth Face

Surface Finish:
Black E-Coat

Material:
Steel

Outside Diameter (in):

11.25

Width (in):

0.25

Number of Vanes:

Solid

Design Type:

Solid

Seated:

No

Dynamically Balanced:

No

Rotor Hat

Hat - Part #:

170-17569

Type:
Dynamic Lug Drive Big Brake - Flared Bell

Material:
Aluminum

Finish Color:

Type III Anodized

Hat Offset Dimension (in):

1.220

Bolt Circle 1:

5 x 4.50

Bolt Circle 2:

Bolt Circle 3:

Bolt Diameter - BC 1:

0.520

Bolt Diameter - BC 2:

0.000

Bolt Diameter - BC 3:

0.000
