MMR Dual Intercoolers for BMW M5 M6 F10 F12 F13 F90 S63 2011-2023

MMX Dual Intercoolers for BMW F1x S63

MMX high-performance intercoolers for the BMW M5 and M6 F1x, as well as the M5 F90 with the S63 engine, significantly improve power and torque by substantially reducing intake air temperature. With their oversized stepped tube and fin core, these intercoolers provide twice the cooling surface and are 28% larger than stock.

The factory intercoolers on the S63 engine have proven to be incapable of handling the demands of high-horsepower and aggressive driving, resulting in significant power losses during demanding driving due to increased intake air temperatures.

Our high-performance intercoolers are the best upgrade available on the market for the BMW S63. The intercooler core was specifically developed for the high demands of the M F1x and F9x. Thanks to their oversized stepped tube and fin core, our high-performance intercoolers provide twice the cooling surface and are 28% larger than stock.
Our development focused on finding the optimal balance of maximum intake air cooling (IAT) with minimal pressure drop. This allowed us to increase the size without increasing lag. By consistently lowering intake air temperatures (IAT), heat soak is minimized, resulting in continuously superior performance. The cool-down times required for the stock intercooler are no longer necessary.

This race-proven intercooler is essential for every tuning stage of any high-performance M-Car with the S63 engine.

Features

28% increase in core size per intercooler compared to stock intercoolers.

Provides a substantial temperature drop in the core, with minimal impact on pressure drop.

Designed and manufactured in the UK.

Anti-corrosion thermal coating.

Easy installation, no cutting or permanent modifications to the vehicle required.

Additional Information

The core uses internal turbulators to enhance its cooling performance, and CFD-optimized cast end tanks contribute to maintaining the best possible airflow through the core.
Vehicle Compatibility

Series

5 Series
6 Series

Chassis Code

F10
F12
F13
F90

Model Year

2011 - 2023

Model Variant

M5
M6

Engine Code

S63
