NGK 48165 U5046 Ignition Coil

Smaller, lighter and faster: the Turbosmart turbocharger series has been developed leveraging modern materials, design and manufacturing techniques to create a range that meets the demands of both motorsport and performance enthusiasts.

Every Turbosmart turbocharger comes standard with everything needed for installation: weld flanges, V-band clamps, gaskets, and oil feed and drain fittings.

The TS-1 series consists of oil-cooled turbochargers with lightweight, precision-cast turbine housings, and a proprietary bearing and main shaft combination that provides unimaginable transient response, with the performance, quality, reliability and support that characterize Turbosmart.

The ultra-low rotating mass of our unique bearing and shaft assembly is combined with aggressive compressor aerodynamics to ensure high performance at low shaft speeds. Additionally, a unique turbine ensures that power is maintained even at high loads and flow rates.
All Turbosmart turbochargers have been designed with a holistic approach to the engine, aiming to achieve power through lower backpressure and high-performance turbines, while being smaller, lighter and offering faster response than other solutions on the market. Available in:

Oil-cooled TS-1 Turbochargers

Oil and water-cooled TS-2 Turbochargers
V-Band connections, various T3 and T4 flange options

Reverse rotation (select sizes)
Various A/R options
Internal and external wastegate options available

Features

Unrivaled transient response
Aggressive aerodynamics with 7+7 aluminum 2618 splitter wheels
Lightweight investment-cast 310s stainless steel turbine housings
Lightweight aluminum compressor covers
CFD-designed housings for optimal air-fuel ratio and flow
Inconel 713C turbine wheel for extreme exhaust gas temperatures
VSR high-speed balanced
Patented dual ceramic ball bearing system
Backplate integrated into the center housing

Specifications

Compressor inlet: 4″ / 101.6 mm
Compressor inducer: 82 mm
Turbine inlet: V-Band (3.00″)
Turbine exducer: 80 mm
Turbine A/R: 0.96

Turbine outlet: V-Band clamp (3.50″)

Weight: 9.63 kg / 21.23 lb

Horsepower: 1225-1445 HP

INCLUDES:

1 Turbosmart Performance Turbocharger

2 Weld flanges (turbine inlet and outlet)

2 V-band clamps (turbine inlet and outlet)

1 Oil drain gasket
