Manley 15022R6-4 H-Tuff Plus Forged Connecting Rods for Mitsubishi Eclipse GST GSX Eagle Talon TSi 2.0 7-Bolt 4G63 4G63T EVO 8-9

Manley 15022R6-4 H-Tuff Plus Forged Rods for Mitsubishi Eclipse GST GSX Eagle Talon TSi 2.0 7-Bolt 4G63 4G63T EVO 8-9

Manufactured from 4340 forgings

Heat treated, stress relieved, shot peened and 100% magnafluxed individually

Weight matched to +/- 1.5 grams
Cap screws are 3/8" ARP 2000 for H-Tuff and 3/8" ARP Custom Age 625+ for H-Tuff Plus

Max horsepower at the flywheel for these rods in a 4-cylinder application is 750 HP with ARP 2000 bolts

and 950 HP with ARP 625+ bolts. In a 6-cylinder application, max horsepower is 1000 HP with ARP 2000 bolts

and 1200 HP with ARP 625+ bolts. H-Tuff Series

• Bridges the gap between our standard, proven H-Beam rods,

and the top-of-the-line, best of the best Turbo Tuff® series

series

• The H-Tuff series offers a stronger rod with more safety margin to handle
higher boost and horsepower levels, at a slightly higher price point

than standard H-Beam rods.

• The H-Tuff series design incorporates a wider beam and larger cross-section thickness in critical areas.

Product available for ordering!
