ZRP L19 Rods for Audi 2.0L TSI Chain Drive, HD Series

They feature a straight cut pin end for increased durability, so they can only be used with aftermarket pistons. The bushings are made from AMPCO 18 material, offering excellent wear and fatigue resistance, and have a radial groove that acts as an oil reservoir. They are shot peened to relieve material stress and undergo multi-stage heat treatment to increase their rigidity. Strict tolerances in the production process ensure a perfect fit and optimize oil clearances. Flex and twist are strictly controlled. Each connecting rod includes ARP 2000 cap screws rated at 220,000 psi; optionally, 260,000 psi ARP L19 material can be purchased as an upgrade. The complete kit is supplied with ARP moly lubricant and full assembly instructions. Additional machining processes

Straight cut pin end - suitable for aftermarket pistons

Dowel bushings for a perfect fit and accurate reassembly

Flanged cap relief for increased rod big end integrity in extreme applications

Thrust face grooves for weight reduction

ZRP Connecting Rod Technical Features

I-beam shape for increased rigidity

Two-piece forging for high strength

Shot peened for increased fatigue resistance

Magnaflux inspection ensures forged material consistency meets our high quality standards

Double ribbed caps for extra support

Multi-stage heat treatment for maximum strength, dimensional stability, and fatigue resistance

CNC machined for superior tolerances, accurate to within 0.0002″

Center-to-center distance maintained under 0.001″ tolerance

Finite Element Analysis (FEA) - computer-generated stress analysis of connecting rods

Optimal balancing for weight-matched sets of ± 1 gram
